Who should use this guide?
Factory owners
Compare automation opportunities using one complete investment and benefit boundary.
Operations and engineering
Validate staffing, output, yield, maintenance and ramp-up assumptions.
Finance and procurement
Convert operational changes into controlled cash flows and lifecycle scenarios.
Two screening calculations
Worked labor example
A factory compares a current line requiring 18 direct workers per shift with a proposed automated line requiring 14. It operates two eight-hour shifts for 250 days per year. Loaded labor cost is 12 per worker-hour, and additional annual automation support is 20,000.
| Calculation | Result |
|---|---|
| Current direct labor | 18 × 2 × 8 × 250 × 12 = 864,000/year |
| Proposed direct labor | 14 × 2 × 8 × 250 × 12 = 672,000/year |
| Automation support | 20,000/year |
| Net annual labor impact | 864,000 - 672,000 - 20,000 = 172,000 |
| Direct labor hours changed | 4 × 2 × 8 × 250 = 16,000 hours/year |
Worked payback example
Assume the complete installed project cost is 650,000. The project provides the 172,000 annual labor benefit above and 90,000 of additional gross contribution from sellable accepted output. It adds 45,000 of annual operating and maintenance cost.
Simple payback = 650,000 / 217,000 = 3.00 years
Simple annual benefit/investment ratio = 33.4%
Five-year simple net benefit = 217,000 × 5 - 650,000 = 435,000
This result excludes the time value of money, tax, financing, depreciation, residual value and changing cash flows. It is a screening case, not an approved financial forecast.
Build the complete installed project cost
Supply scope
Base equipment, options, tooling, format parts, controls, guarding and initial critical spares.
Integration scope
Freight, insurance, duties, tax, unloading, foundations, drainage, platforms and building work.
Service scope
Electrical distribution, steam, water, cooling, compressed air, extraction and wastewater changes.
Implementation scope
Engineering, installation, commissioning, validation, training, trial product, ramp-up loss and contingency.
Include internal project labor and production shutdown when material. Compare quotations only after normalizing scope exclusions, currency, Incoterms, tax treatment and acceptance responsibilities.
Separate real benefits from optimistic assumptions
| Benefit | Required evidence | Common overstatement |
|---|---|---|
| Labor | Role-by-role future staffing and an avoidable cost | Counting every redeployed operator as cash saving |
| Additional output | Constraint increase, demand and contribution per accepted unit | Using sales revenue or nameplate capacity |
| Yield and giveaway | Controlled mass balance and repeatable trial | Applying best trial result to every SKU |
| Quality | Current defect cost and validated future rate | Counting the same material in yield and quality |
| Downtime | Failure history and net unrecovered line loss | Valuing every machine stop as full line revenue |
| Outsourcing or space | Contract or lease cost actually avoided | Claiming theoretical value with no cash change |
Use loaded labor cost correctly
Loaded cost includes wages plus employer-paid benefits, payroll taxes, insurance and other direct employment costs relevant to the jurisdiction. BLS employer-compensation data illustrate why wages alone do not equal employer cost, but a project must use the factory's own payroll and benefit data.
Also include relief, breaks, absence, training, sanitation, quality, supervision and maintenance roles required by the future process. Do not remove safety, food-safety or control responsibilities merely because product handling is automated.
Add recurring ownership costs
- Electricity, steam, water, cooling and compressed air.
- Cleaning water, chemicals, sanitation labor and changeover time.
- Consumables, films, casings, tooling and wear parts.
- Preventive maintenance, service contracts, software and calibration.
- Specialist operators, technicians and external support.
- Expected downtime, startup waste and product-hold risk.
- Insurance, compliance, upgrades and cybersecurity where applicable.
NIST manufacturing research shows that maintenance strategy affects downtime and defects. A low purchase price with weak maintainability or support can have a higher ownership cost.
Move from simple payback to lifecycle value
NIST Handbook 135 explains discounting future cash flows to present value. For investment approval, finance should establish analysis period, discount rate, inflation treatment, tax, depreciation, financing and terminal value. Compare alternatives with the same basis.
Simple payback
Easy screening of recovery time, but ignores benefits after payback and cash-flow timing.
Net present value
Discounts all incremental cash flows and residual value to a common date.
Internal rate of return
Shows the discount rate at which project NPV equals zero, subject to cash-flow limitations.
Run downside, base and upside cases
| Variable | Downside test | Base evidence | Upside condition |
|---|---|---|---|
| Operating days | Demand or staffing constraint | Approved production plan | Contracted growth |
| Labor benefit | Redeployment only | Approved future organization | Agency or overtime elimination |
| Output | Ramp-up and lower utilization | Constraint-based accepted rate | Verified demand and stable performance |
| Yield | No improvement until trial | Controlled production evidence | Validated across product mix |
| Installed cost | Contingency and site risk | Normalized vendor scope | Firm turnkey commitment |
| Maintenance | Critical parts and specialist service | Supplier schedule and site history | Local capability established |
Identify the variables that change the decision. A project that fails with a small reduction in demand or labor realization is not robust even if its base payback appears short.
Nine-step investment review
- Define the business problem. State capacity, labor, quality, safety or continuity need.
- Freeze current baseline. Use accepted output, staffing, yield, downtime and costs over a representative period.
- Define the future process. Include operators, sanitation, maintenance, utilities and changeovers.
- Normalize supplier scope. Build one complete installed-cost boundary.
- Validate benefits. Require a cash mechanism and avoid double counting.
- Model ramp-up. Phase benefits and include trial, training and startup loss.
- Calculate screening payback. Use the same currency and annual basis.
- Complete discounted TCO. Apply finance-approved rates, taxes and life assumptions.
- Verify after startup. Compare actual installed cost, staffing, output, yield and maintenance with the approved case.
Minimum investment-case record
Current and future process maps; SKU and demand forecast; accepted capacity; role-level staffing; loaded labor source; yield and downtime baseline; normalized supplier scope; complete installed cost; annual operating and maintenance schedule; benefit owner; ramp-up curve; downside/base/upside cash flows; discount and tax assumptions; acceptance test; implementation risk; post-project verification date.
Frequently asked questions
How is simple payback calculated?
Divide complete installed project cost by verified annual net cash benefit.
Is payback the same as ROI or NPV?
No. Payback ignores later benefits and discounting. ROI uses a defined return basis; NPV discounts all incremental cash flows.
Does reducing operators guarantee labor savings?
No. A role reduction becomes cash saving only when payroll, recruitment, overtime, agency labor or another cost is actually avoided.
Should additional sales revenue be used as a benefit?
No. Use additional gross contribution after variable costs, and only for output that demand can absorb.
What belongs in TCO?
Acquisition, installation, utilities, operation, maintenance, consumables, support, downtime, upgrades and end-of-life cost, less residual value.
Build the labor case, then screen payback
Calculate role-based annual labor impact before transferring a realizable benefit into the investment model.
Open the Food Production Labor Estimator | Open the Food Machine Payback Estimator
Primary references
- NIST Handbook 135, Life-Cycle Costing Manual, 2022 edition - present-value and lifecycle economic evaluation method.
- U.S. Department of Energy FEMP, Operations and Maintenance Best Practices Guide - installed cost, simple payback, lifecycle cost and operational-efficiency context.
- U.S. Bureau of Labor Statistics, Employer Costs for Employee Compensation - wages, salaries, paid leave, insurance, retirement and legally required employer costs.
- NIST AMS 100-34, Economics of Manufacturing Machinery Maintenance (2020) - maintenance cost, downtime, defect and delay effects.
- NIST, Maintenance Costs and Advanced Maintenance Techniques in Manufacturing Machinery (2021) - maintenance strategy, downtime and defects.
This guide is for preliminary engineering and investment planning. Obtain project-specific tax, accounting, legal and financing review before approval.
